Rubber Insulated Welding Cable
Welding Cable (YH)
Heavy-duty flexible welding cable for arc welding machines and high-current portable equipment
YH series welding cable is a single-core, highly flexible cable designed to carry high welding currents from the welding machine to the electrode holder or workpiece clamp. Constructed with extra-fine Class 6 copper stranding and natural or synthetic rubber insulation, it remains pliable in cold conditions and resists abrasion, oil, and sparks on workshop floors. Rated AC 200V / DC 400V.
Key features
- Extra-fine Class 6 copper stranding (0.16mm wire diameter) for maximum flexibility
- Natural rubber or EPR insulation — remains flexible to -25°C
- Excellent resistance to abrasion, oil, grease, and welding sparks
- Rated AC 200V / DC 400V
- Available sizes: 10mm² to 120mm²
- Standard colours: Black, Orange (for electrode lead identification)
Typical applications
- Manual arc welding (MMA/SMAW) machine connections
- MIG/MAG and TIG welding secondary circuits
- Resistance welding machine bus bars
- High-current portable power connections
- Electroplating and electrolysis equipment
- Battery charger connections for heavy equipment
YH Welding Cable Specifications (Copper Conductor)
Custom sizes available on request — send us your project specification.
| Section (mm²) | Conductor Diameter (mm) | Overall OD (mm) | Weight (kg/km) | Current Rating 60% Duty (A) | Resistance at 20°C (Ω/km) |
|---|---|---|---|---|---|
| 16 | 6.0 | 10.5 | 195 | 120 | 1.16 |
| 25 | 7.5 | 12.5 | 290 | 170 | 0.727 |
| 35 | 8.8 | 14.0 | 390 | 210 | 0.524 |
| 50 | 10.5 | 16.0 | 540 | 260 | 0.387 |
| 70 | 12.5 | 18.5 | 740 | 320 | 0.268 |
| 95 | 14.5 | 21.0 | 990 | 390 | 0.193 |
| 120 | 16.0 | 23.0 | 1240 | 450 | 0.153 |
YH Welding Cable — Official Range and Materials
Source: Huanghe Cables official product data, huanghecables.com/welding-cable.html — type names, constructions and ratings as published; re-typeset here (unit spacing, British spelling), not copied character-for-character
Published cross-section range is 10–120 mm² single core. The rated voltage on the official page reads 600 V; the type description above quotes AC 200 V / DC 400 V from the IEC 60245 type rating. Confirm which rating your specification requires.
| Parameter | Specification |
|---|---|
| Model | YH |
| Construction | Flexible copper conductor, rubber compound insulated |
| Cores | Single core |
| Cross Section Range | 10, 16, 25, 35, 50, 70, 95, 120 mm² |
| Voltage | 600 V |
| Conductor | Tinned copper or flexible copper, class 5 |
| Insulation | Rubber compound (natural rubber, NBR, EPR, CPE or silicone) |
| Colours | Black, red, orange and others |
| Standards | IEC / EN / BS / UL / CSA |
| Certifications | CB Test Certificate / CCC / ISO 9001 / ISO 14001 |
Need a specific rubber compound, colour or drum length?
YH welding cable is produced 10–120 mm² in natural rubber, NBR, EPR, CPE or silicone compound, tinned or bare flexible copper, in black, red, orange and custom colours. Send us the cross-section, compound, colour, drum length and destination port and we will return a stamped data sheet with dimensions and per-metre pricing.
Welding Cable (YH) gallery
Factory & delivery capability
Real photos from our production facility — from raw material to container loading.
Production Line
Quality Testing
Warehouse & Stock
Drum Packaging
Container Loading
Ready to Ship
Frequently asked questions about Welding Cable (YH)
Q.What is the duty cycle rating for welding cable?
Our current ratings are based on 60% duty cycle (standard for manual welding — 6 minutes welding per 10-minute period). For automated welding at 100% duty cycle, derate the current by approximately 25% or select the next larger cable size.
Q.What is the minimum operating temperature?
Standard rubber-insulated welding cable operates from -25°C to +65°C. For extreme cold environments below -40°C, we offer special cold-resistant versions with silicone-rubber or EPR insulation.
Q.Can welding cable be used outdoors permanently?
Welding cable is designed for portable use and is UV and weather resistant to a degree. For permanent outdoor installations, dedicated rubber-sheathed flexible cable (YC/YZ series) with a proper outer sheath is more appropriate.
Q.What is the difference between YH and YHF cable?
YH uses natural rubber insulation. YHF uses chloroprene (neoprene) rubber which offers better oil resistance and flame retardancy. Choose YHF for environments with oil/solvent exposure or where fire safety codes apply.
Q.What lengths are available per coil?
Standard packaging: 50m or 100m per coil, wound on cardboard drums or in PE-wrapped coils. Custom lengths available on request. Export packaging uses wooden drums.
